| Size Range (mm) | W1 | W4 | W5 | pcs/bag | pcs/carton |
|---|---|---|---|---|---|
| 35-40 | QL04A3540 | QL04D3540 | QL04E3540 | 10 | 50 |
| 40-45 | QL04A4045 | QL04D4045 | QL04E4045 | 10 | 50 |
| 45-50 | QL04A4550 | QL04D4550 | QL04E4550 | 10 | 50 |
| 50-55 | QL04A5055 | QL04D5055 | QL04E5055 | 10 | 50 |
| 55-60 | QL04A5560 | QL04D5560 | QL04E5560 | 10 | 50 |
| 60-65 | QL04A6065 | QL04D6065 | QL04E6065 | 10 | 50 |
| 65-70 | QL04A6570 | QL04D6570 | QL04E6570 | 10 | 50 |
| 70-75 | QL04A7075 | QL04D7075 | QL04E7075 | 10 | 50 |
| 75-80 | QL04A7580 | QL04D7580 | QL04E7580 | 10 | 50 |
| 80-85 | QL04A8085 | QL04D8085 | QL04E8085 | 10 | 50 |
| 85-90 | QL04A8590 | QL04D8590 | QL04E8590 | 10 | 50 |
| 90-95 | QL04A9095 | QL04D9095 | QL04E9095 | 10 | 50 |
| 95-100 | QL04A95100 | QL04D95100 | QL04E95100 | 10 | 50 |
| 100-105 | QL04A100105 | QL04D100105 | QL04E100105 | 10 | 50 |
| 105-110 | QL04A105110 | QL04D105110 | QL04E105110 | 10 | 50 |
| 110-115 | QL04A110115 | QL04D110115 | QL04E110115 | 10 | 50 |
| 115-120 | QL04A115120 | QL04D115120 | QL04E115120 | 10 | 50 |
| 120-125 | QL04A120125 | QL04D120125 | QL04E120125 | 10 | 50 |
| 125-130 | QL04A125130 | QL04D125130 | QL04E125130 | 10 | 50 |
| 130-135 | QL04A130135 | QL04D130135 | QL04E130135 | 10 | 50 |
| 135-140 | QL04A135140 | QL04D135140 | QL04E135140 | 10 | 50 |
| 140-145 | QL04A140145 | QL04D140145 | QL04E140145 | 10 | 50 |
| 145-150 | QL04A145150 | QL04D145150 | QL04E145150 | 10 | 50 |
| 150-155 | QL04A150155 | QL04D150155 | QL04E150155 | 10 | 50 |
| 155-160 | QL04A155160 | QL04D155160 | QL04E155160 | — | — |
| Type | Band | Housing | Bridge | Screw | |
| W1 | Zinc plated steel | Zinc plated steel | Zinc plated steel | Zinc plated steel | |
| W4 | AISI 301SS/304SS | AISI 301SS/304SS | AISI 301SS/304SS | A2-70 | |
| W5 | AISI 316SS | AISI 316SS | AISI 316SS | A4-70 |
